| Part No |
90NX09D1-M00KR0 |
| Sales Model Name |
PM1503CDA-S70496WS |
| EAN Code |
4711636456883 |
| UPC Code |
199291456884 |
| WEEE |
1.423 |
| BASE UNIT |
VSNX09D1-BUA001 |
| |
|
| Operating System |
Windows 11 Home - ASUS recommends Windows 11 Pro for business
* Windows 11 Home is available only as the Single Language edition. Learn more about Windows 11 Home Single language: https://support.microsoft.com/article/eaf060a6-3642-4612-6b75-b34e57a08abf |
| Office |
Microsoft Office Home 2024
Microsoft 365 Basic |
| LCD cover-material |
Plastic |
| LCD cover-color |
Misty Grey |
| Top case-material |
Plastic |
| Top case-color |
Misty Grey |
| Bottom case-material |
Plastic |
| Bottom case-color |
Misty Grey |
| Military grade |
US MIL-STD 810H military-grade standard |
| Panel Size |
15.6-inch |
| Backlit |
LED Backlit |
| Brightness |
300nits |
| Resolution |
FHD (1920 x 1080) 16:9 |
| Glare |
Anti-glare display |
| Color gamut |
NTSC: 45% |
| View angle(H/V) |
178/178 |
| Response time(Typ/Max) (ms) |
25/30 |
| Refresh rate |
60Hz |
| Contrast (Typ) |
700:1 |
| Touch Panel |
Non-touch screen |
| Screen-to-body ratio |
87 % |
| IPS-level |
Wide view |
| Processor |
AMD Ryzen™ 5 150 Processor 3.3GHz (16MB Cache, up to 4.55 GHz, 6 cores, 12 Threads) |
| Chipset |
N/A |
| Discrete/Share |
Share |
| Integrated GPU |
AMD Radeon™ 660M |
| VRAM |
N/A |
| How to upgrade memory |
Upgradable; Need to remove bottom/top case |
| Expansion Slot(includes used) |
2x DDR5 SO-DIMM slots
1x M.2 2230 PCIe 4.0x4
1x M.2 2280 PCIe 4.0x4 |
| DIMM Memory |
8GB DDR5 SO-DIMM |
| Total System Memory |
DDR5 8GB |
| Storage |
512GB M.2 2280 NVMe™ PCIe® 4.0 SSD
SSD Housing for storage expansion |
| Front-facing camera |
1080p FHD camera
With privacy shutter |
| Wireless |
Wi-Fi 6E(802.11ax) (Triple band) 2*2 + Bluetooth® 5.4 Wireless Card |
| NumberPad |
N/A |
| FingerPrint |
FingerPrint |
| Keyboard type |
Backlit Chiclet Keyboard with Num-key |
| Keyboard language |
English |
| I/O ports |
2x USB 3.2 Gen 1 Type-A
2x USB 3.2 Gen 2 Type-C support display / power delivery
1x HDMI 1.4, up to 3840x2160p/30Hz
1x 3.5mm Combo Audio Jack
1x RJ45 Gigabit Ethernet |
| Audio |
Audio by Dirac
Built-in speaker
Built-in array microphone |
| Battery |
50WHrs, 3S1P, 3-cell Li-ion |
| AC Adapter |
TYPE-C, 65W AC Adapter, Output: 20V DC, 3.25A, 65W, Input: 100~240V AC 50/60Hz universal |
| Required charging power
|
Min: 55W
Max: 65W
*The indicated wattage is for demonstrating the system’s support capability as required by EU regulations. For optimal system performance, please use the standard-wattage adapter or higher. |
| Dimension (WxHxD) |
35.95 x 23.22 x 1.99 ~ 1.99 cm (14.15" x 9.14" x 0.78" ~ 0.78") |
| Starting Weight (with Battery) |
1.81 kg (3.99 lbs) |
| Starting Weight (w/o Battery) |
1.62 kg (3.57 lbs) |
| Security |
Fingerprint sensor intergrated with Touchpad
Kensington Nano Security Slot™(6x 2.5mm)
BIOS Booting User Password Protection
BIOS Integrity Measurement Support
BIOS Self Recovery
BIOS setup user password
CSME BIOS Redundancy Assistance
Enhanced Password Strength
HDD User Password Protection and Security
Microsoft Security Level 2
Support Absolute Persistence 2.0 (Computrace)
Trusted Platform Module (TPM) 2.0
N/A |
| Antivirus |
McAfee® 1 year |
| MyASUS feature |
System diagnosis
Battery health charging
Fan Profile
Splendid
Function key lock
WiFi SmartConnect
AppDeals
Link to MyASUS |
| MyExpert Features |
ExpertMeet(Only Watermark) |
| Built-in Apps |
AI ExpertMeet (watermark only)
MyASUS |
| Disclaimer for Built-in Apps |
Built-in Apps vary from OS SKU.
*MyASUS/McAfee don't support in Clean Build/without OS/G sku/Win SE/Windows on ARM/Linux OS (ex. Endless, Kylin, Ubuntu) |
| Reparability Index (for Belgium) |
9.4 |
| Reparability Index (for France) |
9.5 |
| Ecolabels & Compliances |
EPEAT Gold with Climate+
Energy star 9.0
FSC Recycled
REACH
RoHS
TCO Certified |
