RUIJIE RG-NBS3100-24GT4SFP-V2 | 24-PORT GIGABIT L2 MANAGED SWITCH |24 GIGABIT RJ45 PORTS |4 SFP SLOTS |19-INCH RACK-MOUNTABLE STEEL CASE | 6 MONTHS WARRANTY SWITCH

Port Specifications
Total number of RJ45 ports: 24
Total number of optical ports: 24
Number of 1GE combo ports: No
Number of 1GE SFP ports: 4
Number of 10GE SFP+ ports: No
Number of 10/100BASE-T ports: No
Number of 10/100/1000BASE-T ports: No
Number of 10/100/1000/2500BASE-T ports: No
Number of 100/1000/2.5G/5G/10GBASE-T ports: No
Module slots: No

Power Supply and Consumption
Power input

220 V AC power supply:
● Rated input voltage: 100 V AC to 240 V AC, 50/60 Hz
● Maximum input voltage: 90 V AC to 264 V AC, 47 Hz to 63 Hz
● Maximum input current: 0.6 A

Maximum power consumption: 21 W

Power output: No
Power supply: Fixed power supply

System Specifications
RAM:  256 MB
Flash memory: 16 MB
Forwarding rate:  41.66 Mpps
Switching capacity: 56 Gbps(bit/s)

Dimensions and Weight
Casing: Metal
Product dimensions (W x D x H): 440 mm x 165 mm x 44 mm (17.32 in. x 6.5 in. x 1.73 in.)
Weight: 1.88 kg (4.14 lbs) (without packaging materials)
Shipping weight: 2.69 kg (5.93 lbs)

Environment and Reliability
Hot swapping of fan modules: No
Fan: Fanless design
Cooling: Natural Cooling
Acoustic noise: No
Mounting options: Rack
Hot swapping of cables: Service ports support hot swapping of cables.
MTBF: 400,000 hours
Operating temperature: 0°C to +50°C (32°F to 122°F)
Storage temperature: –40°C to +70°C (–40°F to +158°F)
Operating humidity: 10% RH to 90% RH (non-condensing)
Storage humidity: 5% RH to 95% RH (non-condensing)

Altitude
Operating altitude: –500 m to +5,000 m (–1,640.42 ft. to
+16,404.20 ft.)
Storage altitude: –500 m to +5,000 m (–1,640.42 ft. to
+16,404.20 ft.)
Corrosion class: No
ESD protection:

Contact discharge: 6 kV
Air discharge: 8 kV


Surge protection:
Service port: ±6 kV for common mode
Power connector: ±6 kV for both common mode and
differential mode
