| Model |
DGS-1210-28 |
| Hardware Version |
Fx |
| Mounting Options |
Desktop or 19” Rack Mount (mounting brackets included) |
| Interfaces |
24 × 10/100/1000BASE-T; 4 × 100/1000 Mbps GbE/SFP combo ports |
| Port Standards |
IEEE 802.3 10BASE-T Ethernet; IEEE 802.3u 100BASE-TX Fast Ethernet; IEEE 802.3u 100BASE-FX; IEEE 802.3ab 1000BASE-T Gigabit Ethernet; IEEE 802.3z 1000BASE-X; IEEE 802.3az Energy Efficient Ethernet (EEE); IEEE 802.3x Flow Control |
| Network Cables |
UTP Cat. 5, Cat. 5e (100 m max.) |
| Duplex Mode |
Full/Half-duplex for 10/100 Mbps; Full-duplex for 1000 Mbps |
| Media Interface Exchange |
Auto MDI/MDIX adjustment for all twisted-pair ports |
| Switching Capacity |
56 Gbps |
| Transmission Method |
Store-and-forward |
| MAC Address Table |
8K entries |
| Static MAC Addresses |
256 entries |
| Maximum 64 Byte Packet Forwarding Rate |
41.7 Mpps |
| Packet Buffer Memory |
4.1 Mbits |
| CPU Memory |
DDR3 128 MB |
| Flash Memory |
32 MB |
| LEDs |
Power (per device); Link/Active/Speed (per port) |
| Power Input |
100 to 240 V AC, 50/60 Hz internal universal power supply |
| Maximum Power Consumption |
17.32 W/100 V; 16.94 W/240 V |
| Standby Power Consumption |
6.49 W/100 V; 6.55 W/240 V |
| Acoustics |
0 dB(A) |
| Heat Dissipation |
59.09 BTU/hr (100 V); 57.79 BTU/hr (240 V) |
| Operating Temperature |
-5 to 50°C |
| Storage Temperature |
-20 to 70°C |
| Operating Humidity |
0% to 95% relative humidity |
| Storage Humidity |
0% to 95% relative humidity |
| Dimensions (L × W × H) |
440 × 140 × 44 mm (17.32 × 5.51 × 1.73 in) |
| Weight |
2.15 kg (4.74 lbs) |
| Certifications |
EMI: CE Class A, VCCI Class A, FCC Class A, BSMI, CQC (only for specific models); Safety: CB, UL, BSMI, LVD, CQC (only for specific models) |
| MTBF |
992,594 hours |
| Link Aggregation |
IEEE 802.3ad; maximum 8 groups per device and 8 ports per group |
| IGMP Snooping |
IGMP v1/v2 Snooping; IGMP v3 awareness; 256 IGMP groups; at least 64 static multicast addresses; IGMP per VLAN; Auto IGMP; IGMP Snooping Querier |
| Spanning Tree Protocol |
802.1D STP; 802.1W RSTP; 802.1s MSTP |
| Jumbo Frame |
Up to 10,000 bytes |
| VLAN |
802.1Q; Max. 256 static VLAN groups; VID 1–4094; Asymmetric VLAN; Auto Voice VLAN; Auto Surveillance VLAN |
| Quality of Service (QoS) |
802.1p QoS; 8 queues per port; Strict and Weighted Round Robin (WRR); Bandwidth Control |
| L3 Features |
IP interface (4 interfaces); IPv6 Neighbor Discovery; Static Routing; 124 IPv4 static route entries; 50 IPv6 static route entries |
| ACL |
Maximum 50 access lists; maximum 768 rules shared by IPv4, MAC and IPv6 |
| Security |
Storm Control; D-Link Safeguard Engine; Traffic Segmentation; SSH v2; TLS v1.3; DoS Attack Prevention; 802.1X; Port Security; ARP Spoofing Prevention; DHCP Server Screening; IP-MAC-Port Binding; ARP Inspection; IPv4/IPv6 Inspection; DHCP Snooping |
| Management |
Web-based GUI; D-Link Network Assistant Utility; Compact CLI; Telnet Server; TFTP Client; SNMP v1/v2c/v3; SNMP Trap; Firmware Backup/Upgrade; Smart Wizard; System Log; SNTP; IPv4/IPv6 Dual Stack; DHCP Auto Configuration; RMONv1; Trusted Host; Dual Image; Dual Configuration |
| Green Technology |
Power saving by Link Status; System Hibernation; Port Shut Off; Cable Length Detection |
