| Printing Technology |
Piezoelectric Printhead |
| Nozzle Configuration |
Black: 180 × 1 nozzlesCyan, Magenta, Yellow: 59 × 1 nozzles per colour |
| Print Direction |
Bi-directional printing |
| Maximum Resolution |
5,760 × 1,440 dpi with Variable-Sized Droplet Technology |
| Minimum Ink Droplet Volume |
3 pl |
| Draft Print Speed – A4 |
Black: Up to 33 ppmColour: Up to 15 ppm |
| ISO 24734 Print Speed – A4 |
Black: Up to 11.0 ipmColour: Up to 6.0 ipm |
| First Page Out Time |
Black: Approx. 10 secondsColour: Approx. 16 seconds |
| Photo Print Speed – 4 × 6 in. |
Border: Approx. 69 secondsBorderless: Approx. 90 seconds |
| Printer Language |
ESC/P-R, ESC/P Raster |
| Automatic Two-Sided Printing |
No |
| Paper Feed Method |
Friction feed |
| Number of Paper Trays |
1 |
| Input Capacity |
Up to 100 sheets of 80 g/m² plain paperUp to 20 sheets of Premium Glossy Photo Paper |
| Output Capacity |
Up to 30 sheets of 80 g/m² plain paperUp to 20 sheets of Premium Glossy Photo Paper |
| Supported Paper Sizes |
A4, A5, A6, B5, B6, Letter, Legal, Indian Legal, 100 × 148 mm, 3.5 × 5 in., 4 × 6 in., 5 × 7 in., 5 × 8 in., 8 × 10 in., 8.5 × 13 in., 16:9 Wide, 16K, Envelopes: #10, DL, C6 |
| Maximum Paper Size |
215.9 × 1,200 mm or 8.5 × 47.24 in. |
| Supported Paper Weight |
Plain Paper: 64–90 g/m²Photo Paper: 102–300 g/m² |
| Print Margin |
3 mm top, bottom, left, and right through custom printer-driver settings |
| Rated Voltage |
AC 220–240 V |
| Rated Frequency |
50–60 Hz |
| Power Consumption |
Operating: 12 WStandby: 5 WSleep: 0.5 WPower Off: 0.1 W |
| Black Ink Bottle |
Page Yield: 4,700 pagesOrder Code: 003 |
| Cyan Ink Bottle |
Composite Page Yield: 7,500 pagesOrder Code: 003 |
| Magenta Ink Bottle |
Composite Page Yield: 7,500 pagesOrder Code: 003 |
| Yellow Ink Bottle |
Composite Page Yield: 7,500 pagesOrder Code: 003 |
| Maintenance Box |
Order Code: C12C939891 |
| Printer Type |
Print Only |
| Photo Printing Noise Level |
Sound Power: 5.4 B(A), Black and ColourSound Pressure: 40 dB(A), Black and Colour |
| Plain-Paper Printing Noise Level |
Sound Power: 6.3 B(A) Black / 6.1 B(A) ColourSound Pressure: 49 dB(A) Black / 48 dB(A) Colour |
| Dimensions (W × D × H) |
361 × 317 × 152 mm |
| Weight |
3.1 kg |
| USB Interface |
USB 2.0 |
| Wireless Connectivity |
Wi-Fi IEEE 802.11b/g/n and Wi-Fi Direct for up to 8 devices |
| Network Protocols |
TCP/IPv4, TCP/IPv6 |
| Network Management Protocols |
SNMP, HTTP, DHCP, APIPA, PING, DDNS, mDNS, SLP, WSD, LLTD |
| Network Printing Protocols |
LPD, IPP, PORT9100, WSD |
| Compatible Software |
Epson Photo+, Epson Device Admin, Epson Remote Services |
| Epson Connect |
Epson Email Print, Remote Print Driver |
| Driverless Printing |
Apple AirPrint, Mopria Print Service, Chrome OS |
| Mobile Application |
Epson Smart Panel |
| Windows Compatibility |
Windows 7, 8, 8.1, 10, and 11 |
| Windows Server Compatibility |
Windows Server 2008, 2012, 2016, 2019, 2022, and 2025 |
| macOS Compatibility |
Mac OS X 10.9.5 or later and macOS 11 or later |
