Cooler Specification

Intel LGA2066, LGA2011-0 & LGA2011-3 (Square ILM), LGA1200, LGA1156, LGA1155, LGA1151, LGA1150 & AMD AM2, AM2+, AM3, AM3+, FM1, FM2, FM2+ (backplate required), AM4
Height (without fan)

160 mm
Width (without fan)

150 mm
Depth (without fan)

135 mm
Weight (without fan)

980 g
Height (with fan)

165 mm
Width (with fan)

150 mm
Depth (with fan)

161 mm
Weight (with fan)

1320 g
Material

Copper (base and heat-pipes), aluminium (cooling fins), soldered joints & nickel plating
Fan compatibility

140x150x25 (with 120mm mounting holes), 140x140x25 (with 120mm mounting holes), 120x120x25
Scope of delivery

- Black NH-D15 heatsink
- 2x NF-A15 HS-PWM chromax.black premium fan
- 2x Low-Noise Adaptor (L.N.A.)
- 4-pin PWM Y-cable
- NT-H1 high-grade thermal compound
- Black SecuFirm2‚Ñ¢ Mounting Kit
- Noctua Metal Case-Badge
FAN Specification
Model

2x Noctua NF-A15 HS-PWM chromax.black
Max. rotational speed (+/- 10%)

1500 RPM
Max. rotational speed with L.N.A. (+/- 10%)

1200 RPM
Min. rotational speed (PWM, +/-20%)

300 RPM
Max. acoustical noise

24,6 dB(A)
Max. acoustical noise with L.N.A.

19,2 dB(A)
Voltage range

12 V
MTTF

> 150.000 h
